Woven Wire Mesh Used for Test Sieve With 20 40 80 100 120 150 200Mesh
Stainless Steel Woven Wire Mesh for Test Sieve
Woven wire mesh is a mainly raw material for test sieve, the test sieve is a professional measuring instrument for laboratory sampling, particle size analysis, separates or classify sands, crushed rock, clays, granite, feldspars, coal, soil, a wide range of manufactured powders, grain and seeds etc. High quality metal wire protects against corrosion and simplifies cleaning, and the metal frame prevent contamination of the sieving material. The meshes come in different materials: stainless steel, brass and copper.
Specifications:
| Outer Sieves Diameter: | 38mm, 100mm, 150mm, 200mm, 250mm, 300mm, 315mm, 400mm, 450mm, 3", 8", 10", 12", 18". |
| Depth: | 1", 1-1/2", 1-5/8", 1.625", 2", 3", 3-1/2", 3.25", 4", 4.25", 6", 8". |
| Mesh/Inch | Wire Diameter | Aperture | Open Area | Weight |
| mm | mm | % | Kgs/㎡ |
| 20 | 0.27 | 1.000 | 62.00 | 0.72 |
| 20 | 0.25 | 1.020 | 64.50 | 0.62 |
| 80 | 0.12 | 0.197 | 38.69 | 0.57 |
| 80 | 0.10 | 0.217 | 46.92 | 0.40 |
| 100 | 0.10 | 0.154 | 36.75 | 0.50 |
| 100 | 0.08 | 0.174 | 46.92 | 0.32 |
| 120 | 0.06 | 0.151 | 51.34 | 0.21 |
| 150 | 0.06 | 0.109 | 41.68 | 0.27 |
| 200 | 0.05 | 0.077 | 36.75 | 0.25 |
Other specifications according to your requirements.
Stainless steel wire:
SU302,304,316,304L,316L,310S,321 ,hastelloy wire, inconel wire, monel wire, incoloy wire, nickel wire etc.
Stainless Steel extruder screen Product Features:
Strong corrosion resistance, easy to clean;
High screening precision, high efficiency;
Wear resistance, easy to use and suitable for graded screening;
Low cost, easy to process;
Long service life.
Applications:
Industries: Chemical industries; Pharmaceutical industries; Dyes industries; Soil testing; Cosmetic industries; Sugar,tea & coffee industries; Foundries; Cement industries.
Test Sieve Used as: Air Jet Sieves, Cement Wet Washing, Coffee Bean Grading, Grain Sieves, Grid Sieves, Garden sieve, Dry sieve, Wet washing sieve, etc.
